Duplex 2205 Stainless Steel Plate 4mm 5mm 6mm 8mm 10mm 12mm 16mm 20mm SS Plate

Brand Name : TISCO

Model Number : 2205 / 1.4462 / UNS S32205 / UNS S31803

Certification : ISO

Place of Origin : China

MOQ : 1 Ton

Price : 2500-3500 USD/Ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products Name : Stainless Steel Plate

Grade : 2205 / 1.4462 / UNS S32205 / UNS S31803

Thickness : 0.6-30.0mm

Standard : ASTM EN GB

Width : 1000mm 1219mm 1500mm

Surface : 2B NO.1

Brand : TISCO BAOSTEEL

MOQ : 1 Ton

Contact Now

Duplex 2205 Stainless Steel Plate 4mm 5mm 6mm 8mm 10mm 12mm 16mm 20mm SS Plate

Products Specification

Products Name duplex stainless steel plate
Grade 2205 / S31803 / S32205 / 1.4462
Thickness Cold Rolled 0.6 - 3.0mm , Hot Rolled 3.0 - 80.0mm
Width 1000mm 1219mm 1500mm 1800mm 2000mm
Standard Size 1000*2000mm 1219*2438mm 1500*6000mm 1800*6000mm 2000*6000mm or cutting as request
Brand POSCO TISCO BAOSTEEL JISCO ESS
Other Grade 304 316L 309S 310S 321 347 2507 904L 254SMO.etc
Service Cutting

Standard Size of our 2205 Duplex Stainless Steel Plate in Stock

Cold Rolled 2205 duplex stainless steel sheet
0.4*1219*2438mm 0.5*1219*2438mm 0.6*1219*2438mm 0.8*1219*2438mm 1.0*1219*2438mm
1.2*1219*2438mm 1.5*1219*2438mm 2.0*1219*2438mm 2.5*1219*2438mm 3.0*1219*2438mm
Hot Rolled 2205 duplex stainless steel plate
3.0*1500*6000mm 4.0*1500*6000mm 5.0*1500*6000mm 6.0*1500*6000mm 8.0*1500*6000mm
10.0*1500*6000mm 12.0*1500*6000mm 14.0*1500*6000mm 16.0*1500*6000mm 20.0*1500*6000mm
6.0*2000*6000mm 8.0*2000*6000mm 10.0*2000*6000mm 12.0*2000*6000mm 14.0*2000*6000mm
16.0*2000*6000mm

Chemical Composition:
Stainless steel plate is an austenitic stainless steel that has a composition of chromium, nickel, and manganese. Its chemical composition is as follows:

Grade Chemical Composition (%)
c si Mn P s Ni Cr Mo
201 ≤0.15 ≤0.75 5.5-7.5 ≤0.06 ≤ 0.03 3.5-5.5 16.0-18.0 -
301 ≤0.15 ≤1.0 ≤2.0 ≤0.045 ≤ 0.03 6.0-8.0 16.0-18.0 -
304 ≤0.08 ≤1.0 ≤2.0 ≤0.045 ≤ 0.03 8.0-10.5 18.0-20.0 -
304L ≤0.03 ≤1.0 ≤2.0 ≤0.035 ≤ 0.03 9.0-13.0 18.0-20.0 -
316 ≤0.08 ≤1.0 ≤2.0 ≤0.045 ≤ 0.03 10.0-14.0 16.0-18.0 2.0-3.0
316Ti ≤0.08 ≤0.75 ≤2.0 ≤0.045 ≤0.03 10.0-14.0 16.0-18.0 2.0-3.0
310S ≤0.08 ≤1.5 ≤2.0 ≤0.045 ≤0.03 19-22 24-26
316L ≤0.03 ≤1.0 ≤2.0 ≤0.045 ≤ 0.03 12.0-15.0 16 .0-1 8.0 2.0-3.0
321 ≤0.08 ≤1.0 ≤2.0 ≤0.035 ≤ 0.03 9.013 17.0-1 9.0 -
405 ≤0.08 ≤1.0 ≤1.0 ≤0.04 ≤0.03 0.6 11.5-14.5
409 ≤0.08 ≤1.0 ≤1.0 ≤0.04 ≤0.03 0.6 11.5-14.5
409L ≤0.08 ≤1.0 ≤1.0 ≤0.04 ≤0.03 0.6 11.5-14.5
410 ≤0.15 ≤1.0 ≤1.0 ≤0.035 ≤ 0.03 - 11.5-13.5 -
430 ≤0.12 ≤0.75 ≤1.0 ≤0.040 ≤ 0.03 ≤0.60 16.0-18.0 -
420 ≤0.05 ≤1.0 ≤1.0 ≤0.04 ≤0.03 0.75 12-14 0.5
430 ≤0.12 ≤1.0 ≤1.0 ≤0.04 0.03 0.5 16-18 0.75
444 ≤0.025 ≤1.0 ≤1.0 ≤0.04 0.03 1 17.5-19.5 1.75-2.5
904L ≤0.02 ≤1.0 ≤2.0 ≤0.045 0.035 23-28 19-23 4.0-5.0
2205 ≤0.03 ≤1.0 ≤2.0 ≤0.03 0.02 4.5-6.5 22.0-23.0 3.0-3.5
2507 ≤0.03 ≤0.8 ≤1.0 ≤0.035 0.02 6.0-8.0 24-26
3.0-5.0


Thickness and Width:

The thickness and width of stainless steel plates can vary according to specific needs and applications. Generally speaking, the thickness of stainless steel plates can range from a very thin few millimeters to tens of millimeters, and the width is usually between tens of millimeters and several meters.

We can provide different specifications and sizes of stainless steel plates, and can choose the appropriate thickness and width according to the specific needs.

2205 stainless steel plate

Item 2205 Stainless Steel Plate (Hot rolled, cold rolled)
Standard ASTM A240/A480M, ASTM B443/SB443, ASTM B625, B709, B618, B435, ASTM A480, A895, A693, DIN 10088, EN 10028, JIS G4304, JIS G4305, etc.
Thickness Hot Rolled ( 3.0-300mm) Cold Rolled (0.3-16mm)
Width 1000-3000mm
Length Any as your requirements 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Material 302, 301,310S, 310, 309, 309S, 316, 316L, 316Ti, 317, 317L, 321, 321H, 347, 347H, 304, 304L,etc.
Specification Cold Rolled: 1219mm * 2438mm (4′ x 8′), 1219mm * 3048mm (4′ x 10′), 1220mm * 2440mm, 1250mm * 2500mm or as your requirement.
Hot rolled: 1500mm * 2000mm, 1000mm * 3000mm, 1500mm * 4000mm, 1500m * 6000mm or as your requirement.
Surface
2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sandblast, Brush, etching, etc
Value Added Services Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc.
MTC Mill Test Certificate, Available as per EN 10204 3.1
Package
Standard Export Seaworthy Package, or as required.


Hot Rolled and Cold Rolled
Stainless steel plate can be manufactured using either hot rolled or cold rolled techniques. Hot rolling involves heating the steel above its recrystallization temperature and then passing it through rollers to form the desired shape. Cold rolling, on the other hand, involves passing the steel through rollers at room temperature to reduce its thickness.

Different Finishes
Stainless steel plate comes in different finishes that can affect its appearance and properties. Here are some common finishes:

Different Finishes
2B: This is a smooth, reflective finish that is produced by cold rolling followed by annealing and descaling.
No.1: This is a rough, dull finish that is produced by hot rolling followed by annealing and pickling.
SB: This is a satin finish that is produced by applying a fine abrasive material to the surface of the steel.
BA: This is a bright, mirror-like finish that is produced by buffing the surface of the steel with a fine abrasive material.
HL: This is a hairline finish that is produced by brushing the surface of the steel with a fine abrasive material.
Mirror: This is a highly reflective finish that is produced by polishing the surface of the steel with a very fine abrasive material.

Duplex 2205 Stainless Steel Plate 4mm 5mm 6mm 8mm 10mm 12mm 16mm 20mm SS PlateDuplex 2205 Stainless Steel Plate 4mm 5mm 6mm 8mm 10mm 12mm 16mm 20mm SS PlateDuplex 2205 Stainless Steel Plate 4mm 5mm 6mm 8mm 10mm 12mm 16mm 20mm SS PlateDuplex 2205 Stainless Steel Plate 4mm 5mm 6mm 8mm 10mm 12mm 16mm 20mm SS Plate
