Soft Anneal AISI 301 Stainless Steel Strip 0.1-2.0mm

Name: Soft Anneal AISI 301 Stainless Steel Strip 0120mm
Brand: TISCO
Price: 2400 USD

Quality Soft Anneal AISI 301 Stainless Steel Strip 0.1-2.0mm for sale

Brand Name : TISCO

Model Number : 201 202 301 304 316L 321 310S 410 430 440C

Certification : ISO

Place of Origin : China

MOQ : 2 Ton

Price : 2400 - 3500 USD/Ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : 20Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : stainless steel strip

Thickness : 0.1 - 10.0mm

Width : within 1500mm

MOQ : 2 Ton

Grade : 200 series 300 series 300 series

Surface : BA 2B NO.4 HL 8K NO.1

Standard : ASTM EN GB JIS

Packing : wooden frame and water proof paper

Contact Now

Soft Anneal AISI301 Stainless Steel Strip Thickness 0.1 - 2.0mm Thickness SS Strips

What Is 301 Stainless Steel Strip

The 301 stainless steel strip has high strength after cold working, which is the first choice for constant force springs manufacturing.

The constant force spring, also known as torsion spring, which is made of 301 stainless steel strip.

The stress can determine the spring diameter, strength and working life.

The action of a constant force spring is similar to the move of stretching a ribbon.

When the spring stretches and rewinds, the working part is tangent to the circle of the spring itself.

As long as the diameter of the spring is constant, the force of the spring is constant.

In an extremely long spring design work, the diameter has an advantage, and the tension increases slightly as the spring stretches.

However, this increased part is relatively small relative to the stretched length and can be ignored in many real life applications.

What Are The Springs Applications?

According to the application principle of them, constant force springs can be divided into linear motion constant type and rotary motion constant torque type.

When linear stretched, the unit of force will be kilogram, N, pound.

Constant force springs can be used for vehicles, automotive industry, counterweights, power sources, power cords, cordless curtains, generator radios and some toys.

What Are The Advantages Of 301 Stainless Steel Strip For Springs?

Austenitic stainless steel strip for springs mainly includes SUS301-CSP and SUS304-CSP.

Compared with 304 stainless steel strip, SUS301 spring steel strip has a slightly lower corrosion resistance, but it is more suitable for spring production with a lower cost.

After the special production process of continuous bright annealing and rolling, which can help achieve good hardness and be suitable for bending processing.

Especially in terms of mechanical properties, 301 spring strip is very good, which is unmatched by manganese steel.

How To Produce One Roll 301 Stainless Steel Strip?

Our high strength precision grade 301 stainless steel strip for springs is available in total annealed condition as well as a variety of hardness choice, such as 1/4 hard, half hard, 3/4 hard, full hard and super extra hard.

The thickness range is from 0.02mm to 3mm.

The maximum hardness of cold rolled 301 stainless steel strip we could produce is up to 630 HV.

Meanwhile, the tensile strength is over 2000 N/mm².

Chemical Composition of Stainless Steel 301 Strip

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
301	Min	–	–	–	–	–	16.0	2.00	10.0	–
301	max	0.08	2	0.75	0.045	0.03	18.0	3.00	14.0	0.1

ASTM A240 SS 301 Strip Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB) max
201	515	205	35%	75	205

Stainless Steel 301 Strip Physical Properties

Physical Properties (Room Temperature)
Specific Heat (0-100°C)	500	J.kg-1.°K-1
Thermal Conductivity	14.6	W.m -1.°K-1
Thermal Expansion	16.5	mm/m/°C
Modulus Elasticity	193	GPa
Electrical Resistivity	7.4	μohm/cm
Density	7.99	g/cm3

Equivalent Grades of 301 Stainless Steel Strip

STANDARD	UNS	JIS	WERKSTOFF NR.	AFNOR	BS	GOST	EN
SS 301	S30100	SUS 301	1.4310	–	–	–	–
